HD2 Series Inverter Function Parameter List
-250-
Function
code
Name
Description
Default
value
Modify
large or integral time is too small, system
oscillation and large overshoot may occur; if
proportional gain is too small, stable oscillation or
speed offset may occur.
Speed loop PI parameter is closely related to the
system inertia, you should make adjustment
according to different load characteristics based
on the default PI parameter to fulfill different
needs.
Setting range of P23.00: 0.0–200.0
Setting range of P23.01: 0.000–10.000s
Setting range of P23.02: 0.00Hz–P23.05
Setting range of P23.03: 0.0–200.0
Setting range of P23.04: 0.000–10.000s
Setting range of P23.05: P23.02–P00.03 (Max.
output frequency)
P23.06
Speed loop
output filter
0–8 (corresponds to 0–2^8/10ms)
0
○
P23.07
Slip
compensation
coefficient of
vector control
(motoring)
Slip compensation coefficient is used to adjust the
slip frequency of vector control to improve system
speed control precision. You can effectively control
the static error of speed by adjusting this
parameter properly.
Setting range: 50–200%
100%
○
P23.08
Slip
compensation
coefficient of
vector control
(generating)
100%
○
P23.09
Current loop
proportional
coefficient P
Note:
1. These two parameters are used to adjust PI
parameters of current loop; it affects dynamic
response speed and control precision of the
system directly. The default value needs no
adjustment under common conditions.
2. Applicable to SVC mode 0 (P00.00=0), SVC
mode 1 (P00.00=1), and FVC (P00.00=3)
Setting range: 0–65535
1000
○
P23.10
Current loop
integral
coefficient I
1000
○
P23.11
Speed loop
differential gain
0.00–10.00s
0.00s
○
