IMO HD2-3.7A-43 - Page 272

HD2 Series Inverter Function Parameter List
-263-
Function
code
Name
Description
Default
value
Modify
terminal status of
programmable
card
Bit0 indicates PRO1, and Bit1 indicates PRO2.
P27.24
AI1 of the
programmable
card
0–10.00V/0.00–20.00mA
AI1 value from the programmable card.
0
●
P27.25
AO1 of
programmable
card
0–10.00V/0.00–20.00mA
AO1 value from the programmable card.
0
●
P27.26
Length of data
sent by
programmable
card and PZD
communication
object
0x01–0x28
Ones place: Number of the programmable card
sent. The number of sent data is 12*digit on the
ones place.
3: The inverter sends 24+60 variables, and the
programmable card sends 36 variables. This is the
default delivery method for generic variables.
5: The inverter sends 48+60 variables, and the
programmable card sends 60 variables. This is
how the programmable card on the inverter
communicates with the DP/CANopen/PN card
through (24+24) PZDs.
8: The inverter sends 96+96 variables, and the
programmable card sends 96 variables.
You can use other values (not 3/5/8), but only if
you know which variables correspond to the
selected values. Using other values only changes
data volumn sent by the programmable card, but
not the number of variables sent by the inverter.
The inverter still sends 24+60 by default.
Tens place: Card that communicates with the
programmable card via PZD (Only valid when the
ones of P27.26 is 5)
0: DP
1: CANopen
2: PN
Note: P27.26 can be changed at any time, but the
change will only take effect after the re-power on.
0x03
○
