HD2 Series Inverter Communication
-318-
Function
Address
Data description
R/W
Synchronous machine
Bit4: =0: No overload alarm =1: Overload alarm
Bit5–Bit6: =00: Keypad-based control =01:
Terminal-based control
=10: Communication-based control
Bit7: Reserved
Bit8: =0: Speed control =1: Torque control
Bit9: =0: non-position control =1: Position control
Bit10–bit11: =0: Vector 0 =1: Vector 1
=2: Closed-loop vector
=3: Space voltage vector
inverter fault code
2102H
See the description of fault types.
R
inverter identification
code
2103H
HD2-----0x01A0
R
Running frequency
3000H
0–Fmax (unit: 0.01Hz)
Compatible
with CHF100A
and CHV100
communication
addresses
R
Set frequency
3001H
0–Fmax (unit: 0.01Hz)
R
Bus voltage
3002H
0.0–2000.0 V (unit: 0.1V)
R
Output voltage
3003H
0–1200V (unit: 1V)
R
Output current
3004H
0.0–3000.0A (unit: 0.1A)
R
Rotating speed
3005H
0–65535 (unit: 1RPM)
R
Output power
3006H
-300.0–+300.0% (unit: 0.1%)
R
Output torque
3007H
-250.0–+250.0% (unit: 0.1%)
R
Closed-loop setting
3008H
-100.0–+100.0% (unit: 0.1%)
R
Closed-loop feedback
3009H
-100.0–+100.0% (unit: 0.1%)
R
Input state
300AH
000–3F
Corresponding to the local
HDIB/ HDIA/S4/S3/S2/S1
R
Output state
300BH
000–0F
Corresponding to the local
RO2/RO1/HDO/Y1
R
Analog input 1
300CH
0.00–10.00V (unit: 0.01V)
R
Analog input 2
300DH
0.00–10.00V (unit: 0.01V)
R
Analog input 3
300EH
-10.00–10.00V (unit: 0.01V)
R
Analog input 4
300FH
R
Read input of
high-speed pulse 1
3010H
0.00–50.00kHz (unit: 0.01Hz)
R
Read input of
high-speed pulse 2
3011H
R
Read current step of
3012H
0–15
R
