HD2 Series Inverter Expansion Cards
-338-
Indicator
Definition
Function
blinks periodically after the expansion card is properly
connected to the control board (the period is 1s, on for
0.5s, and off for the other 0.5s); and it is off when the
expansion card is disconnected from the control board.
LED4
Power
indicator
This indicator is on after the IO expansion card is
powered on by the control board.
The HD2-E-IO2 expansion card can be used in scenarios where the I/O interfaces of the inverter
cannot meet the application requirements. It can provide 4 digital inputs, 1 PT100 temperature
measurement input (PT1+), 1 PT1000 temperature measurement input (PT2+), and 2 relay outputs. It
is user-friendly, providing relay outputs and digital inputs through European-type screw terminals and
temperature measurement inputs through spring terminals.
HD2-E-IO2 terminal function description
Category
Symbol
Name
Function
Power
PW
External power
supply
The working power of digital input is
provided by an external power supply.
Voltage range: 24(-20%)–48VDC (+10%),
24(-10%)–48VAC (+10%)
+24V
Internal power
User power provided by the inverter.
Max. output current: 200mA
COM
Power reference
Common terminal of +24V
Digital input
S5—COM
Digital input 5
Internal impedance: 6.6kΩ
Supported external power: 24(-20%)–
48VDC (+10%), 24(-10%)–48VAC (+10%)
Supporting internal power 24V
Bi-directional input terminals, supporting
NPN/PNP modes
Max. input frequency: 1kHz
All are programmable digital input
terminals. You can set the terminal
function via function codes.
S6—COM
Digital input 6
S7—COM
Digital input 7
S8—COM
Digital input 8
Temperature
detection
input
PT1+
PT100 input
Independent PT100 and PT1000 inputs.
PT1+ connects to PT100, and PT2+
connects to PT1000.
1. Resolution: 1°C
2. Range: -20°C–150°C
3. Detection accuracy: 3°C
4. Supporting offline protection
PT2+
PT1000 input
PT-
Reference input of
PT100/PT1000
Zero potential reference of
PT100/PT1000
