HD2 Series Inverter Expansion Cards
-360-
Indicator
Name
Description
properly connected to the control board (the
period is 1s, on for 0.5s, and off for the other 0.5s).
Off: The expansion card is disconnected from the
control board.
LED2
Disconnection
indicator
This indicator blinks only if A1 or B1 signal is
disconnected during encoder rotating; and it is on
in other cases.
LED3
Power indicator
On: The control board feeds power to the PG
card.
The HD2-E-PGIM expansion card can be used in combination with multiple types of incremental
encoders through different modes of wiring. It is user-friendly, adopting spring terminals.
HD2-E-PGIM terminal function description
Signal
Port
Description
PWR
Encoder power
Voltage: 5 V/12 V ±5%
Max. output: 150 mA
Select the voltage class through the DIP switch
SW1 based on the voltage class of the used
encoder.
PGND
A1+
Encoder interface
1. Supporting push-pull interfaces of 5 V/12 V
2. Supporting open collector interfaces of 5 V/12 V
3. Supporting differential interfaces of 5 V
4. Response frequency: 200 kHz
A1-
B1+
B1-
Z1+
Z1-
A2+
Pulse setting
1. Supporting the same signal types as the
encoder signal types
2. Response frequency: 200 kHz
A2-
B2+
B2-
Z2+
Z2-
AO+
Frequency-divided
output
1. Differential output of 5 V
2. Supporting frequency division of 1–255, which
can be set through P20.16 or P24.16
AO-
BO+
BO-
ZO+
ZO-
The following figure shows the external wiring of the expansion card used in combination with an
