HD2 Series Inverter Basic Operation Guidelines
-41-
Level 1
Level 2
Level 3
Level 4
P17: State Viewing Func
P17.xx
P18: CI-IpCtrlStateView
P18.xx
P19: Ex-card StateView
P19.xx
P93: Tension control state
viewing func
P93.xx
Fault types
/
P07.27: TypeofLatelyFault
P07.28: Typeof1stLastFault
P07.29:
Typeof2ndLastFault
P07.30: Typeof3rdLastFault
P07.31: Typeof4thLastFault
P07.32: Typeof5thLastFault
Fault recording
parameters
/
P07.33: RunFreq
atLatelyFault
...
P07.xx: xx state of fault xx
Clear fault
records
/
Sure to clear fault records?
Modified
parameters
/
Pxx.xx: Modified parameter
1
Pxx.xx: Modified parameter
2
Pxx.xx: Modified parameter
xx
Customize
Home
parameters
Stopped-state parameters
/
Running-state parameters
/
Motor parameter
autotune
/
Ensure motor nameplate
parameters are set
correctly.
Complete para rotary
autotune
Complete para static
autotune
Partial para static autotune
Complete para rotary
autotune 2 (for AM)
Partial para static autotune
2 (for AM)
Copy
parameter/Restore
/
MemArea1: BACKUP01
Upload local func para to
keypad
Download all func para from
