HD2 Series Inverter Basic Operation Guidelines
-80-
Function
code
Name
Description
Default
value
1: Restart is enabled
P01.22
Waiting time of restart after
power outage
0.0–3600.0s (valid when P01.21 is 1)
1.0s
P01.23
Start delay
0.0–60.0s
0.0s
P01.24
Stop speed delay
0.0–100.0s
0.0s
P01.25
Open loop 0Hz output
selection
0: No voltage output
1: With voltage output
2: Output as per DC brake current of stop
0
P01.26
Deceleration time of
emergency-stop
0.0–60.0s
2.0s
P01.27
Time of starting section of
deceleration S curve
0.0–50.0s
0.1s
P01.28
Time of ending section of
deceleration S curve
0.0–50.0s
0.1s
P01.29
Short-circuit brake current
0.0–150.0% (of rated inverter output
current)
0.0%
P01.30
Hold time of short-circuit
brake at startup
0.00–50.00s
0.00s
P01.31
Hold time of short-circuit
brake at stop
0.00–50.00s
0.00s
P01.32
Pre-exciting time of jogging
0–10.000s
0.000s
P01.33
Starting frequency of braking
for jogging to stop
0–P00.03
0.00Hz
P01.34
Delay to enter sleep
0–3600.0s
0.0s
P05.01–
P05.06
Digital input function
selection
1: Forward running
2: Reverse running
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
21: Acceleration/deceleration time
selection 1
22: Acceleration/deceleration time
selection 2
30: Acceleration/deceleration disabled
/
P08.06
Running frequency of jog
0.00Hz–P00.03 (Max. output frequency)
5.00Hz
