Chapter 5 Relay Ladder Logic Programming 106
-
HMI function instruction
1. HMI can display character, built-in Chinese, user-defined Chinese.This information cannot be edited
through keypad.
2. HMI can display function current value (T, C, R, G and DR), analog input/output value (A, AT, AQ). This
information cannot be edited through keypad.
3. HMI can display preset value of function (T, C, R, G and DR). This information can be edited through
keypad.
4. HMI display state of coil (I, X, Z, M and N), state of M and N can be edited through keypad.
5. Once more than one HMI enabled at the same time, press changing page button to display other HMI
screen.
6. When another HMI is enabled, iSmart can auto-determine whether does HMI screen display the present
page or change to the new HMI screen; it depends on the HMI code. For example, HMI keeps H01 screen
as the present screen even though H02 coil be exercised.
Keypad instruction
SEL
Under status 1 or 2, go into status 3.
Under status 3, go into status 4.
Under status 4, change function preset type.
↑ or ↓
Under status 1, find the nearest HMI whose mode is 1.
Under status 2, find the nearest enabled HMI.
Under status 3, move cursor up or down.
Under status 4, change data and number, function preset data; change coil state
(SEL+↑ or ↓)
Under status 1, find the nearest HMI whose mode is 1.
Under status 2, find the nearest enabled HMI.
Under status 3, move cursor up or down.
← or →
Under status3 or 4, move cursor lift or right.
OK
Validate editing and store automatic.
ESC
Abrogate operation.
