General Specifications
iSmart is a miniature smart Relay with a maximum of 44 I/O points and can be programmed in Relay Ladder
Logic or FBD (Function Block Diagram) program. The iSmart can expand to its maximum I/O count by adding 3
groups of 4-input and 4-output modules.
Power Supply
Input Power Voltage Range
DC Models: 12-28.8V
AC Models: 85-265V
24V AC Models: 20.4-28.8V
Power Consumption
24VDC: 12-point :125mA
20-point: 185mA
100-240VAC: 100mA
24VAC: 290mA
Wire Size (all terminals)
AWG 14/ψ2.6mm
2
Programming
Programming languages
Ladder/Function Block Diagram
Program Memory
600 Lines or 500 Function Blocks
Programming storage media
Flash
Execution Speed
5ms/cycle
LCD Display
4 lines x 16 characters
Timers
Maximum Number
Ladder: 31; FBD: 250
Timing ranges
0.01s–9999min
Counters
Maximum Number
Ladder: 31; FBD: 250
Highest count
999999
Resolution
1
RTC (Real Time Clock)
Maximum Number
Ladder: 31; FBD: 250
Resolution
1min
Time span available
week, year, month, day, hour, min
Analog compare
Maximum Number
Ladder: 31; FBD: 250
Compare versus other inputs
Numeric values or function block current value, such as
Analog input(A), Timer, Counter, Temperature Input (AT),
Analog Output (AQ), Analog*gain + Offset,
AS, MD,
PI, MX, AR , DR …
Environmental
Enclosure Type
IP20
Maximum Vibration
1G according to IEC60068-2-6
Operating Temperature Range
-4° to 131°F (-20° to 55°C)
Storage Temperature Range
-40° to 158°F (-40° to 70°C)
