Chapter 10 External memory 2
iSmart Storage Card Instruction
iSmart can use SD card as External memory for data transfer:
1. Read-write card: copy user programs (screen keys, PC upper computer, iSmart automatic operation) by reading and
writing SD card.
2. Record and output data: iSmart can record some data in operation according to the user's program and output it in a
fixed format.
3. Formatting card: iSmart only supports the micro SD card in the format of FAT32 file system to store programs. If
the memory card is used in other formats, please format the card into FAT32 format first.
4. Read configuration file: read SD configuration file to set iSmart, such as IP address, gateway and so on.
# iSmart only supports standard capacity SD and high capacity SDHC standard cards, the maximum card capacity is
32GB
Read/Write program with SD card
1.Read program from SD card to SMT(keypad)
Use standard type (with LCD display and rubber key) ; You can directly use the LCD screen and button menu to
SD card operation; select "card-->PLC" , you will get in next menu, you will find SD card information on display, if SD
card is installed inside, click "OK", user program will write into iSmart from SD card.
The current status of SD card will be displayed on sub-menu.
a. Whether the SD card is detected in card slot
b. The remaining capacity of SD card
CLEAR PROGRAM
PLC->SD CARD
> SD CARD -> PLC
SYSTEM SET
PLC->SD CARD
STORAGE: 29714MB
>YES
NO
Note :
#It is allowed to write user program from SD card to iSmart when iSmart is in the STOP status.
#If there is any problem during program update, please re-start the input power and re-update it again.
2. Write user program into SD card(keypad)
Using iSmart with LCD display and button function , Please select "PLC-->card" , you will get in next menu, you will
find SD card information on display, if SD card is installed inside, please click "OK", user program will write into SMT
from SD card.
>PLC-> SD CARD
SD CARD -> PLC
