IMO iSmart V4 - Chapter 7 Hardware Specification

Chapter 7 Hardware Specification 190
Normal Specification
Content
Specification
Mode of user program
Ladder & FBD
Environmental
Operation temperature
-4° to 131°F (-20° to 55°C)
Storage temperature
-40° to 158°F (-40° to 70°C)
Maximum Humidity
90% (Relative, non-condensing)
Operation Gas
No corrosive gases
Maximum Noise
Maximum Vibration
0.075mm amplitude, 1.0g acceleration
according to IEC60068-2-6
Shock Resistance
peak value 15g, 11ms
according to IEC60068-2-27
ESD Contact ±4KV, air discharge ±8KV
EFT
Power AC: ±2KV DC: ±1KV
CS 0.15~80MHz 10V/m
RS 80~1000MHz 10V/m
EMI
EN55011 class B
installation
Enclosure Type
IP20
Mounting mode
Direct Mounting or DIN-rail (35mm) Mounting
Direction
According to chapter 2: Installing
Wiring
AWG 14/ψ2.6mm
2
size
2×90×59.6 mm(W×L×H) Din rail
72×126×59.6 mm(W×L×H) Direct
