IMO iSmart V4 - Mounting

Chapter 2 Installation 15
Mounting
DIN-rail Mounting
The iSmart relay should always be mounted vertically. Press the slots on the back of the iSmart and expansion
module plug CONNECTOR onto the rail until the plastic clamps hold the rails in place. Then connect the expansion
module and CONNECTOR with the Master (press the PRESS-BUTTON simultaneously)
