IMO iSmart V4 - Page 24

Chapter 2 Installation 13
Ma
ximum Load
Resistive: 8A /point
Inductive: 4A /point
Maximum operating time
15ms (normal condition)
Life expectancy (rated load)
100k operations
Minimum load
16.7mA
Transistor Outputs
PWM max. output frequency
1.0kHz (0.5ms on,0.5ms off)
Standard max. output frequency
100Hz
Voltage specification
10-28.8VDC
Current capacity
1A
Maximum Load
Resistive: 0.5A/point
Inductive: 0.3A/point
Minimum Load
0.2mA
