Chapter 3 Program Tools 36
T
he below table show an example for the setting value and output results.
Mode Register
Output Val u e Register
AQ output value
Channel1
DRD0=0
AQ output mode 1: voltage mode
and reset value when stop;
DRD4=3000
AQ01=732
(DRD4/4.095)
AQ output 7.32V
Channel2
DRD1=1
AQ output mode 2: Current mode
and reset value when stop;
DRD5=A01*4.095
Current mode 0~2047
AQ02=A01
Current mode 0~500
Channel3
DRD2=2
AQ output mode 3: voltage mode
and keep value when stop;
DRD6= V01*4.095
Voltage mode 0~4095
AQ03=V01
Voltage mode 0~1000
Channel4
DRD3=3
AQ output mode 4: Current mode
and keep value when stop;
DRD7=2047
AQ04=500
(DRD7/4.095)
AQ output 20.00mA
※ Whe
n output value type of AQ is set to constant, AQ output value changed by DR value (AQx=DRx/4.095);
※ When output value type of AQ is set to other parameters variables, DR value changed by AQ output value
(DRx=AQx*4.095).
