Chapter 4: Parameter passing 62
Exa
mple2:
MD01 current value passing to other function block as preset value:
When B006(MD01)=430, MD01’s inner value 430 is passed to other function block as preset
value. Passing to AQ01 automatically as 4.30V, Passing to B001(G01) automatically as 4.30,
Passing to B002(T01 time base is 0.01s) automatically as 4.30s, Passing to B003(T02 time base is
0.1s) automatically as 43.0s, Passing to B004(T03 time base is 1s) automatically as 430s, Passing
to B005(C01) automatically as 430:
