Inovance IS620P Series User Manual

Chapter 1 Servo System Selection IS620P User Manual
- 14 -
Cable Name Cable Model
Cable
Length
(mm)
Cable Appearance
Servo motor
encoder cable
S6-L-P00-3.0 3000
DB44 plug
Note: DB44 is an attached plug, used to connect the CN1
terminal.
L±15 mm
S6-L-P00-5.0 5000
S6-L-P00-10.0 10000
S60-L-P00-3.0 3000
DB44 plug
Note: DB44 is an attached plug, used to connect the CN1
terminal.
L±15 mm
S60-L-P00-5.0 5000
S60-L-P00-10.0 10000
S6-L-P01-3.0 3000
DB44 plug
Note: DB44 is an attached plug, used to connect the CN1
terminal.
L±15 mm
S6-L-P01-5.0 5000
S6-L-P01-10.0 10000
Servo
drive to PC
communication
cable
S6-L-T00-3.0 3000
3000±30 mm
Communication
cable for multi-
drive parallel
connection
S6-L-T01-0.3 300
300±10 mm
