Inovance IS620P Series - Group H12: Multi-Speed Function Parameters

IS620P User Manual Chapter 7 Function Code Table
- 197 -
Function
Code
Parameter Name Setting Range Unit Default
Effective
Time
Property
Control
Mode
H11 85
Acceleration/
Deceleration
time of 15th
displacement<
0–65535 ms (s) 10 Immediate
During
running
P
H11 86
Waiting time
after 15th
displacement
0–10000 ms (s) 10 Immediate
During
running
P
H11 87
16th
displacement
-1073741824
to 1073741824
Reference
unit
10000 Immediate
During
running
P
H11 89
Maximum
running
speed of 16th
displacement
1–6000 rpm 200 Immediate
During
running
P
H11 90
Acceleration/
Deceleration
time of 16th
displacement<
0–65535 ms (s) 10 Immediate
During
running
P
H11 91
Waiting time
after 16th
displacement
0–10000 ms (s) 10 Immediate
During
running
P
Group H12: Multi-Speed Function Parameters
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H12 00
Multi-speed
running mode
0: Stop after a single
running (speed selection
in H12-01)
1: Cyclic running (speed
selection in H12-01)
2: Switchover by DI
- 1 Immediate At stop S
H12 01
End speed
No. in speed
reference
1–16 - 16 Immediate At stop S
H12 02
Running time
unit
0: sec
1: min
- 0 Immediate At stop S
H12 03
Acceleration
time 1
0–65535 ms 10 Immediate At stop S
H12 04
Deceleration
time 1
0–65535 ms 10 Immediate At stop S
H12 05
Acceleration
time 2
0–65535 ms 50 Immediate At stop S
H12 06
Deceleration
time 2
0–65535 ms 50 Immediate At stop S
