Chapter 7 Function Code Table IS620P User Manual
- 192 -
Group H11: Multi-Position Function Parameters
Function
Code
Parameter Name Setting Range Unit Default
Effective
Time
Property
Control
Mode
H11 00
Multi-position
running mode
0: Stop after a
single running
(position
selection in
H11-01)
1: Cyclic
running
(position
selection in
H11-01)
2: DI
switchover
(position
selection by
DI)
3: Sequential
running
(position
selection in
H11-01)
1 Immediate At stop P
H11 01
End position No.
in displacement
reference
1–16 1 Immediate At stop P
H11 02
Margin
processing
method
Valid when
H11-00 ≠ 2.
0: Complete
the remaining
distance
1: Start running
again from
position 1
0 Immediate At stop P
H11 03 Time unit
0: ms
1: s
1 0 Immediate At stop P
H11 04
Displacement
reference type
0: Relative
displacement
reference
1: Absolute
displacement
reference
1 0 Immediate At stop P
H11 05
Start position
of sequence
running
0–16 1 0 Immediate At stop P
H11 12 1st displacement
-1073741824
to 1073741824
Reference
unit
10000 Immediate
During
running
P
