Inovance IS620P Series - 750 W (Vn = 3000 Rpm, Vmax = 6000 Rpm)

IS620P User Manual Chapter 2 Mounting Dimensions of Servo System
- 27 -
3) 750 W (Vn = 3000 rpm, Vmax = 6000 rpm)
19
-0.013
0
φ
25
A
0.02 A
35
3
70
-0.03
0
φ
0.03
φ
A
0.
06
A
LG
LL
500
500
27
80
TP
EQS
7 x 4
φ
R8 x 4
EQS
51.5
90
φ
45°
15.5
-0.10
0
6
-0.03
0
0.012 A
Shaft end
6
-0.018
0
6
-0.018
0
Flat key
Connector Power Side Brake Side Encoder Side
Plastic housing EL-4Y (CWB in Zhejiang) AMP 172165-1 AMP 172169-1
Terminal 422.6006.0 (CWB in Zhejiang) AMP 770834-1 AMP 770834-1
Servo Motor Model LL (mm) LG (mm) TP (mm) Weight (kg)
ISMH1-75B30CB-U***X 135.5 (182.5) 7.8 M6 × 10 2.7 (3.1)
Note
This series servo motors are no longer manufactured.
