Chapter 7 Function Code Table IS620P User Manual
- 178 -
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H07 12
External
reverse torque
limit
0.0–300.0 % 300.0 Immediate
During
running
PST
H07 17
Speed limit
source
0: Internal (in torque
control)
1: External V-LMT setting
2: H07-19/H07-20 as
internal speed limit source
selected by FunIN.36
(V-SEL)
- 0 Immediate
During
running
T
H07 18
V-LMT
selection
1: AI1
2: AI2
- 1 Immediate
During
running
T
H07 19
Forward speed
limit/Speed
limit 1 in torque
control
0–6000 rpm 3000 Immediate
During
running
T
H07 20
Reverse speed
limit/Speed
limit 2 in torque
control
0–6000 rpm 3000 Immediate
During
running
T
H07 21
Base value for
torque reached
0.0–300.0 % 0.0 Immediate
During
running
PST
H07 22
Threshold of
torque reached
valid
0.0–300.0 % 20.0 Immediate
During
running
PST
H07 23
Threshold of
torque reached
invalid
0.0–300.0 % 10.0 Immediate
During
running
PST
H07 40
Speed limit
window in the
torque control
mode
0.5–30.0 ms 1.0 Immediate
During
running
T
