Chapter 2 Mounting Dimensions of Servo System IS620P User Manual
- 34 -
2.3.6 Overall Dimensions of the ISMH4 Series Z Servo Motor
(Vn = 3000rpm, Vmax = 6000 rpm)
1) 400 W
LL
30
3
LG
0.06
A
16.5
0.03
φ
A
A
0.02 A
50
-0.025
0
φ
14
-0.011
0
φ
500
500
27
60
41.5
TP
EQS
R5 x 4
EQS
70
φ
5.5 x 4
φ
5
-0.03
0
11
-0.10
0
0.010 A
Shaft end
5
-0.018
0
5
-0.018
0
Flat key
Connector Power Side Brake Side Encoder Side
Plastic housing EL-4Y (CWB in Zhejiang) AMP 172165-1 AMP 172169-1
Terminal 422.6006.0 (CWB in Zhejiang) AMP 770834-1 AMP 770834-1
Servo Motor Model LL (mm) LG (mm) T (mm) TP (mm) Weight (kg)
ISMH4-40B30CB-U***X 147.5 5.8 5 M5 × 8 1.7
Note
This series servo motors are no longer manufactured.
