17
Fig. 3.14 Z-axis Components
3.7 Hot Bed Components
The hot bed components consist of printing build plate, high-temperature resistant magnet, coaming
and heating film. The printing build plate of the printer is a magnetic plate, and 18 high-temperature
resistant magnets are installed on the hot bed substrate, which can adsorb the printing build plate to
the hot bed substrate in a flat and firm manner. The hot bed substrate has four leveling screws.
Manually level these screws according to the guidance of the operation interface when necessary.
Fig. 3.15 Hot Bed Components
