30
Fig. 4.19 Material Database
Note: These material process parameters are only used for printer operations except for formal
printing. Such operations include material loading, material unloading, leveling, XY calibration, Z
calibration, preheating, and heat hold, etc. During formal printing, the printer will run the parameters
of the loaded G-code command file, instead of the preset parameters in the printer.
In the user-defined interface, you can click to create a new material print process. Enter
corresponding parameters and click OK to save.
Click to modify, copy or delete the existing material process parameters, and click "Finish" to
save the above operations.
Fig. 4.20 User-defined Material Database
Click in the user-defined interface to export existing printing process parameters or
import external parameters. Select the path to save or read parameters. It facilitates parameter
transplantation.
