The UAV flies outside (later-
ally or vertically) of the space
previously dedicated for the
flight.
Action 1 (before take-off)
Before you take off you can assure the UAV will stay
in the allocated space. You can limit the maximum
distance and height of the airspace the Intel Falcon
8+ UAV is flying in by setting specific values which
will not be exceeded by the UAV. The center of this
bounding box is set to the position of the UAV where
Bounding Box is activated.
To set these boundaries from the Main Screen of the
Status Display (see “STATUS DISPLAY” on
page 166):
1. Push ENT in the Main Screen.
The menu is opened
2. Use the arrow RIGHT/LEFT buttons to select
Settings.
3. Push ENT.
The Settings menu is opened.
4. Use the arrow RIGHT/LEFT buttons to select
Bounding Box.
5. Push ENT.
The respective menu is opened. Radius is
highlighted.
6. Push ENT.
The field behind Radius is highlighted.
7. Use the arrow RIGHT/LEFT buttons to determine
the radius the UAV should fly in.
The radius can be set from 10 m to 1000 m.
8. Push ENT.
The value is stored.
Radius is highlighted.
9. Push the arrow RIGHT button one time to select
Height.
10.Push ENT.
The field behind Height is highlighted.
11.Use the arrow RIGHT/LEFT buttons to determine
the height the UAV should not exceed.
The height can be set from 10 m to 300 m.
12.Push ENT.
The value is stored.
Height is highlighted.
Table 3.5: Operational guidelines in case of emergency (continued)
EVENT POSSIBLE ACTION

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
