Intel
®
Server Board S5500BC TPS Functional Architecture
Revision 1.8 Intel order number: E42249-009 29
The Intel
®
Xeon
®
processor 5500 series and 5600 series on sockets 1 and 2 in a dual-processor
configuration are completely autonomous. DIMMs routed to sockets are isolated and can be
initialized locally, including RAS configurations. The Intel
®
Server Board S5500BC provide one
set of RAS questions in the BIOS Setup and can configure common RAS features across the
sockets. If one socket fails the RAS population requirements, the BIOS sets all channels to
Independent Channel mode. The rules on channel population and channel matching vary by the
RAS mode used. Note that support of RAS modes requires matching DIMM population between
channels (sparing, mirroring, and lockstep) requiring ECC DIMMs be populated.
You can populate channels in any order in Independent Channel Mode. You can populate both
channels in any order and have no matching requirements. All channels must run at the same
interface frequency, but individual channels may run at different DIMM timings (RAS latency,
CAS latency, and so forth).
3.2.5 Channel Mirroring Mode
The Intel
®
Xeon
®
processor 5500 series and 5600 series supports channel mirroring to
configure the available channels of DDR3 DIMMs in a mirrored configuration. Unlike channel
sparing, the mirrored configuration is a redundant image of the memory and can continue to
operate when sporadic uncorrectable errors occur.
3.2.6 Demand and Patrol Scrub
The Intel
®
Integrated Memory Controller supports demand and patrol scrubbing. A scrub fixes a
correctable error in memory. A 4-byte ECC is attached to each 32-
detected when the ECC calculated from the payload does not match the ECC read from
memory. The error is corrected by modifying the ECC, payload, or both, and then writing both
the ECC and payload back to memory. Only one demand or patrol scrub can be completed at a
time. Patrol scrubs are intended to ensure that data with a correctable error does not remain in
DRAM long enough to cause further corruption and an uncorrectable particle error. The Intel
®
QuickPath Memory Controller issues a Patrol Scrub at a rate sufficient to write every line once a
day. The maximum is one scrub every 82 ms with 64 GB of memory.
3.3 Intel
®
I/O Hub (IOH) 5500 chipset
The Intel
®
I/O Hub (IOH) 5500 chipset component provides a connection point between various
I/O components and Intel
®
QuickPath Interconnect based processors. The following table shows
the features supported by the chipset.
Table 11. Intel
®
IOH 5500 Chipset Features
Intel
®
QuickPath
Interconnect Ports
Intel
®
Xeon
®
processor 5500 series
and Intel® Xeon processor 5600
series
The Intel
®
IOH 5500 chipset on the Intel
®
Server Board S5500BC have the following features:
Two Intel
®
QuickPath Interconnect interfaces with full-width links (20 lanes in each
direction).
