Intel SC5650BCDP Technical Product Specification

Connector / Header Locations and Pin-outs Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
98
6.8 SGPIO Header
One 4-Pin SGPIO Connector (J1C1).
Table 55. SGPIO connector Pin-out (J1C1)
Pin
Signal Name
1
SCLK
2
SLOAD
3
SDATAOUT0
4
SDATEOUT1
6.9 Chassis Intrusion Header
A 2-pin Chassis intrusion header (J8B3) is provided. This is intended to support micro switches
that close, making a connection to ground when the chassis is opened or removed. The
intrusion signal is routed to the Integrated BMC internal intrusion circuit, which resides in the
RTC well.
Table 56. Chassis Intrusion connector Pin-out (J8B3)
Output
Signal Name
To BMC
FM_IBMC_INTRUDER_HDR_N
To FP
FM_IBMC_INTRUDER_HDR
6.10 SMB Hot-Swap Backplane (HSBP) Header
Table 57. SMB HSBP connector Pin-out (J9B1)
Pin
Signal Name
1
SMB_HSBP_5V_DAT
2
GND
3
SMB_HS BP_5V_CLK
4
P5V Pull-up
