9. Power and Environmental Specifications
9.1 Intel
®
Server Board S5500BC Design Specifications
Operating the server board at conditions beyond the specifications outlined in the following table
may cause permanent damage to the system. Exposure to maximum conditions for extended
periods may impact system reliability.
Table 64. Server Board Design Specifications
0º C to 55º C (32º F to 131º F), at product
airflow specification
Non-Operating Temperature
-40º C to 70º C (-40º F to 158º F)
± 5% of all nominal voltages
50 G trapezoidal waveform. Velocity change of
170 inches/sec
Shock (packaged):
< 20 lbs
36 inches
30 inches
24 inches
18 inches
12 inches
9 inches
5 Hz to 500 Hz 3.13
random.
Note: Intel
®
Server Boards support add-in peripherals and contain a number of high-density
VLSI and power delivery components which require proper airflow for cooling. Intel develops
and tests chassis so when they are used with Intel
®
server building blocks, the integrated
system will meet component thermal requirements. If Intel components are not installed, it is the
responsibility of the system integrator to consult vendor datasheets and operating parameters to
determine the air flow requirements for their specific application and environmental conditions.
Intel Corporation cannot be held responsible if components fail or the server board does not
operate correctly when used outside of the published operating parameters.
9.2 Baseboard Power Requirements
This section reviews the power supply design guidelines for a system with an Intel
®
Server
Board S5500BC. This section also provides voltage and current specifications and power
supply on/off sequencing characteristics. This section specifies the power supply requirements
Intel used to develop a power supply for the Intel
®
Server System SR1630BC and Intel
®
Server
System SC5650BCDP.
