Intel SC5650BCDP Technical Product Specification

Connector / Header Locations and Pin-outs Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
92
Pin
Name
Slot
Name
Pin
B34
PETxN4
GND
A34
B35
GND
PERxP4
A35
B36
GND
PERxN4
A36
B37
PETxP5
GND
A37
B38
PETxN5
GND
A38
B39
GND
PERxP5
A39
B40
GND
PERxN5
A40
B41
PETxP6
GND
A41
B42
PETxN6
GND
A42
B43
GND
PERxP6
A43
B44
GND
PERxN6
A44
B45
PETxP7
GND
A45
B46
PETxN7
GND
A46
B47
GND
PERxP7
A47
B48
PRSNT2#
PERxN7
A48
B49
PE Strap
GND
A49
6.4 RMM3 Connector
The Intel
®
Sever Board S5500BC provides a connector (J3C1) to support a RMM3 card. The
RMM3 card provides the Integrated BMC with an additional dedicated network interface. The
dedicated interface uses a separate LAN channel. The RMM3 provides additional flash storage
for advanced features such as the WS-MAN. The following table shows the pin-out settings for
this connector.
Table 46. RMM3 Connector Pin-out (J3C1)
Pin
Signal Name
Pin
Signal Name
1
P3V3
2
RMI_IBMC_MAC_MDIO
3
P3V3
4
RMII_IBMC_MAC_MDC
5
GND
6
RMII_IBMC_GCM4_RXD<1>
7
GND
8
RMII_IBMC_GCM4_RXD<0>
9
GND
10
RMII_IBMC_GCM4_CRS_DV
11
GND
12
CLK_50M_GCM4
13
GND
14
RMII_IBMC_GCM4_RX_ER
15
GND
16
RMII_IBMC_GCM4_TX_EN
17
GND
18
Key
19
GND
20
RMII_IBMC_GCM4_TXD<0>
21
GND
22
RMII_IBMC_GCM4_TXD<1>
23
P3V3
24
SPI_IBMC_BK_CS_N
25
P3V3
26
TP_GCM4_P26
27
P3V3
28
SPI_IBMC_BK_DO
29
GND
30
SPI_IBMC_BK_CLK
31
GND
32
SPI_IBMC_BK_DI
33
GND
34
FM_GCM4_PRSNT_N
