Server Board S5500BC TPS BIOS Setup Utility
Revision 1.8 Intel order number: E42249-009 69

Advanced

Serial Port Configuration
Serial A Enable
Enabled/Disabled
Address
3F8h / 2F8h / 3E8h / 2E8h
IRQ
3 or 4
Serial B Enable
Enabled/Disabled
Address
3F8h / 2F8h / 3E8h / 2E8h
IRQ
3 or 4


Figure 25. Setup Utility — Serial Port Configuration Screen Display
Table 22. Setup Utility — Serial Ports Configuration Screen Fields
Setup Item
Options
Help Text
Serial A
Enable
Enabled
Disabled
Enable or Disable Serial port A.
Address
3F8h
2F8h
3E8h
2E8h
Select Serial port A base I/O address.
IRQ
3
4
Select Serial port A interrupt request (IRQ) line.
Serial B
Enable
Enabled
Disabled
Enable or Disable Serial port B.
Address
3F8h
2F8h
3E8h
2E8h
Select Serial port B base I/O address.
IRQ
3
4
Select Serial port B interrupt request (IRQ) line.
5.3.2.2.5 USB Configuration Screen
The USB Configuration screen allows the user to configure the USB controller options.
To access this screen from the Main screen, choose Advanced > USB Configuration.
