BIOS Setup Utility Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
Maximize Memory below 4GB
Memory Mapped I/O above 4GB
Figure 27. Setup Utility — PCI Configuration Screen Display
Table 24. Setup Utility — PCI Configuration Screen Fields
Maximize Memory
below 4GB
If enabled. the BIOS maximizes usage of memory
below 4 GB for OS without PAE by limiting PCIE
Extended Configuration Space to 64 buses.
Memory Mapped I/O
above 4GB
Enable or disable memory mapped I/O of 64-bit
PCI devices to 4 GB or greater address space.
Onboard video controller.
Warning: System video is completely disabled if
this option is disabled and an add-in video adapter
is not installed.
When disabled, the system
requires an add-in video
card in order for the video
to be seen.
If enabled. both the onboard video controller and
an add-in video adapter are enabled for system
video. The onboard video controller becomes the
primary video device.
If enabled. loads the embedded option ROM for
the onboard network controllers.
Warning: If [Disabled] is selected, NIC1 cannot be
used to boot or wake the system.
If enabled. loads the embedded option ROM for
the onboard network controllers.
Warning: If [Disabled] is selected, NIC2 cannot
be used to boot or wake the system.
If enabled. loads the embedded option ROM for
the onboard network controllers.
Warning: If [Disabled] is selected, NIC1 and NIC2
cannot be used to boot or wake the system.
This option is grayed out
and not accessible if either
the NIC1 or NIC2 ROMs
are enabled.
