Server Board S5500BC TPS BIOS Setup Utility
Revision 1.8 Intel order number: E42249-009 67
Advanced
Mass Storage Controller Configuration
Intel(R) Entry SAS RAID Module
Enabled / Disabled
Configure Intel(R) Entry SAS RAID
Module
LSI
®
Integrated RAID / Intel
®
ESRTII
Onboard SATA Controller
Enabled / Disabled
Configure SATA Mode
ENHANCED / COMPATIBILITY / AHCI / SW
RAID
 SATA Port 0
Not Installed/<Drive Info.>
 SATA Port 1
Not Installed/<Drive Info.>
 SATA Port 2
Not Installed/<Drive Info.>
 SATA Port 3
Not Installed/<Drive Info.>
 SATA Port 4
Not Installed/<Drive Info.>
 SATA Port 5
Not Installed/<Drive Info.>
Figure 24. Setup Utility — Mass Storage Controller Configuration Screen Display
Table 21. Setup Utility — Mass Storage Controller Configuration Screen Fields
Setup Item
Options
Help Text
Comments
Intel(R) Entry SAS
RAID Module
Enabled
Disabled
Enabled or Disable the Intel(R)
SAS Entry RAID Module
Unavailable if the SAS Module
(AXX4SASMOD) is not present.
Configure Intel(R) Entry
SAS RAID Module
LSI
®
Integrated
RAID
Intel
®
ESRTII
LSI
®
Integrated RAID - Supports
RAID 0, RAID 1, and RAID 1e, as
well as IT (JBOD) mode;
Intel
®
ESRTII - Intel
®
Embedded
Server RAID Technology II, which
supports RAID 0, RAID 1, RAID
10 and RAID 5 mode. RAID 5
support requires optional Software
RAID 5 Activation Key
Unavailable if the SAS Module
(AXX4SASMOD) is disabled or
not present.
Onboard SATA
Controller
Enabled
Disabled
Onboard Serial ATA (SATA)
controller.
