Intel SC5650BCDP Technical Product Specification

Product Overview Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
2
2. Product Overview
The Intel
®
Server Board S5500BC are monolithic printed circuit board (PCB) that supports the
high-density 1U rack-mount server and 5U pedestal server market.
2.1 Feature Set
Table 1: Feature Description
Feature
Description
Processors
LGA 1366 sockets supporting up to two Intel
®
Xeon
®
processor 5500 series and 5600
series with Intel
®
QuickPath Interconnect (QPI) and Integrated Memory controllers.
Memory
Eight DDR3 DIMM slots supporting DDR3 800/1066/1333 MT/s ECC Registered DIMM
and ECC unbuffered DIMM. Four slots support CPU_1 and four slots support CPU_2.
Note: Mixed memory is not tested or supported. Non-ECC memory is not tested and is
not recommended for use in a server environment
Chipset
 Intel
®
I/O Hub (IOH) 5500 chipset
 Intel
®
82801Jx I/O Controller Hub 10 Raid (ICH10R)
 ServerEngines* LLC Pilot II BMC controller (Integrated BMC)
Onboard Connectors /
Headers
 Eight 240-Pin DDR3 DIMM connectors
 Three PCI Express* Gen2 x8 connectors
 One PCI Express* Gen1 x4 connector
 One 5-V PCI 32-bit/33MHz connector
 Two stacked RJ-45 connectors with Magnetics and LEDs and two USB combo
connectors
 One external Serial Port Header (9 pin)
 Two internal USB 2x5 pin headers, each supports two USB 2.0 ports
 One 24-pin main power connector
 One 8-pin CPU power connector
 One 5-pin auxiliary power connector
 One DB-15 VGA connector
 One DB-9 serial port connector
 Six 7-pin SATA II connectors
 One 4-pin SGPIO connector
 Five 4-
 One 24-pin Front Panel connector
 One 2-pin Chassis Intrusion header
 One Intel
®
Remote Management Module 3 (RMM3) connector
