Intel
®
Server Board S5500BC TPS Jumper Block Settings
Revision 1.8 Intel order number: E42249-009 101
Table 60. Jumper Block Matrix
Jumper Name
Pins
What happens at system reset…
J8C1: BMC Force
Update
1-2
BMC Firmware Force Update Mode Disabled (Default)
2-3
BMC Firmware Force Update Mode Enabled
J2D1: Password Clear
1-2
These pins should have a jumper in place for normal system operation. (Default)
2-3
If these pins are jumpered, administrator and user passwords will be cleared on
the next reset.
Note: These pins should not be jumpered for normal operation.
J2D2: CMOS Clear
1-2
These pins should have a jumper in place for normal system operation. (Default)
2-3
If these pins are jumpered, the CMOS settings will be cleared on the next reset
Note: These pins should not be jumpered for normal operation.
Jumper Name
Pins
What happens at system reset…
J1A1: BIOS Recovery
1-2
These pins should have a jumper in place for normal system operation.(Default)
2-3
The main system BIOS will not boot with these pins jumpered.
Note: The system will boot from EFI-bootable recovery media with a recovery
BIOS image.
J8B5: ME Force Update
1-2
These pins should have a jumper in place for normal system operation. (Default)
2-3
ME force update model.
