Intel SC5650BCDP Technical Product Specification

Connector / Header Locations and Pin-outs Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
94
Table 48. VGA Connector Pin-out (J7A1)
Pin
Signal Name
1
VGA_RED
2
VGA_GREEN
3
VGA_BLUE
4
RESERVED
5
GND
6
GND
7
GND
8
GND
9
5V
10
GND
11
RESERVED
12
DDCDAT
13
HSYNC
14
VSYNC
15
DDCCLK
6.6.2 SATA II Connectors
The Intel
®
Server Board S5500BC provides six Serial ATA connectors (J1B4, J1B3, J1A2, J1B1,
J1B2, and J2B1).
Table 49. SATA Connector Pin-out (J1B4, J1B3, J1A2, J1B1, J1B2, and J2B1)
Pin
Signal Name
Description
1
GND
GND1
2
SATA#_TX_P_C
Positive side of transmit differential pair
3
SATA#_TX_N_C
Negative side of transmit differential pair
4
GND
GND2
5
SATA#_RX_N_C
Negative side of Receive differential pair
6
SATA#_RX_P_C
Positive side of Receive differential pair
7
GND
GND3
