BIOS Setup Utility Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
5.3.2.6.1 Add New Boot Option Screen
The Add Boot Option screen allows the user to remove an EFI boot option from the boot order.
To access this screen from the Main screen, select Boot Options > Delete Boot Options.
Figure 34. Setup Utility — Add New Boot Option Screen Display
Table 31. Setup Utility — Add New Boot Option Fields
Create the label for the new boot
option.
Select one from list
provided.
Select one file system from the list.
Enter the path to boot option in the
format
\path\filename.efi
5.3.2.6.2 Delete Boot Option Screen
The Delete Boot Option screen allows the user to remove an EFI boot option from the boot
order.
To access this screen from the Main screen, select Boot Options > Delete Boot Options.
Select one to Delete / Internal EFI Shell
Figure 35. Setup Utility — Delete Boot Option Screen Display
