Intel SC5650BCDP Technical Product Specification

Intel
®
Server Board S5500BC TPS Connector / Header Locations and Pin-outs
Revision 1.8 Intel order number: E42249-009 89
6. Connector / Header Locations and Pin-outs
6.1 Board Connectors
Table 41. Board Connector Matrix
Connector
Quantity
Reference Designators
Connector Type
Pin Count
Memory
8
J1D1,J1D2,J1D3,J1D4,J8K2,J8K1,J9K2,J9
K3
DDR3 DIMM Sockets
240x8
PCI Express* x8
3
J4B1,J4B2,J5B1
Card Edge
98x3
PCI Express* x4
1
J2B2
Card Edge
64
PCI 32/33
1
J3B1
Card Edge
120
SATA
6
J1B4,J1B3,J1A2,J1B1,J1B2,J2B1
App-specific Plug
7x6
SGPIO
1
J1C1
Header
4
IPMB
2
J8B1
Header
4
HSBP
1
J9B1
Header
4
Fans
5
J3K1,J7K2,J3K2,J8K3,J8B4
Header
4x5
RMM3
1
J3C1
RMM3 connector
34
Power Supply
3
J9B3
J7K1
J9E1
Header
24
8
5
USB
4
J1A3
J2A2
J5A1
J6A1
Dual USB/LAN Connector on
the rear panel; dual USB
headers on the board
10
10
22
22
VGA
1
J7A1
Connector
15
Serial Port
2
J8A1
J9A1
DB-9 rear connector
2x5 Header
9
10
GigE
2
J5A1
J6A1
USB/LAN combo connector
22
22
Front Panel
1
J9E2
Header
24
SATA Key
1
J7B1
Header
3
Intrusion Detect
1
J8B3
Header
2
Battery
1
Battery Holder
2
