BIOS Setup Utility Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
5. BIOS Setup Utility
5.1 Logo / Diagnostic Screen
The Logo / Diagnostic Screen appears in one of two forms:
If Quiet Boot is enabled in the BIOS setup, a logo splash screen is displayed. By default,
Quiet Boot is enabled in the BIOS setup. If the logo is displayed during POST, press
<Esc> to hide the logo and display the diagnostic screen.
If a logo is not present in the flash ROM, or if Quiet Boot is disabled in the system
configuration, the summary and diagnostic screen displays.
The diagnostic screen displays the following information:
BIOS ID
Platform name
Total memory detected (total size of all installed DDR-3 DIMMs).
Processor information (Intel branded string, speed, and number of physical processors
identified).
Keyboards detected, if plugged in.
Mouse devices detected, if plugged in.
5.2 BIOS Boot Popup Menu
The BIOS Boot Specification (BBS) provides for a Boot Popup Menu invoked by pressing the
<F6> key during POST. The BBS popup menu displays all available boot devices. The list order
in the popup menu is not the same as the boot order in BIOS setup; it simply lists all the
bootable devices from which the system can be booted.
5.3 BIOS Setup Utility
The BIOS Setup utility is a text-based utility that allows the user to configure the system and
view current settings and environment information for the platform devices. The Setup utility
controls the platform's built-in devices, boot manager, and error manager.
The BIOS Setup interface consists of a number of pages or screens. Each page contains
information or links to other pages. The advanced tab in Setup displays a list of general
The following sections describe the look and behavior for platform setup.
5.3.1 Operation
The BIOS Setup has the following features:
