Intel SC5650BCDP Technical Product Specification

BIOS Setup Utility Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
70
Advanced
USB Configuration
Detected USB Devices
<Total USB Devices in System>
USB Controller
Enabled / Disabled
Legacy USB Support
Enabled / Disabled / Auto
Port 60/64 Emulation
Enabled / Disabled
Make USB Devices Non-Bootable
Enabled / Disabled
USB Mass Storage Device Configuration
Device Reset timeout
10 seconds / 20 seconds / 30 seconds / 40
seconds
Mass Storage Devices:
<Mass storage devices one line/device>
Auto / Floppy/Forced FDD/Hard Disk/CD-ROM
USB 2.0 controller
Enabled / Disabled
Figure 26. Setup Utility — USB Controller Configuration Screen Display
Table 23. Setup Utility — USB Controller Configuration Screen Fields
Setup Item
Options
Help Text
Comments
Detected USB
Devices
Information only. Shows number of
USB devices in the system.
USB Controller
Enabled
Disabled
[Enabled] - All onboard USB controllers are turned on and
accessible by the OS.
[Disabled] - All onboard USB controllers are turned off and
inaccessible by the OS.
Legacy USB
Support
Enabled
Disabled
Auto
USB device boot support and PS/2 emulation for USB
keyboard and USB mouse devices.
[Auto] - Legacy USB support is enabled if a USB device is
attached.
Grayed out if the USB Controller is
disabled.
Port 60/64
Emulation
Enabled
Disabled
I/O port 60h/64h emulation support.
Note: This may be needed for legacy USB keyboard
support when using an OS that is USB unaware.
Grayed out if the USB Controller is
disabled.
