Intel
®
Server Board S5500BC TPS BIOS Setup Utility
Revision 1.8 Intel order number: E42249-009 71
Make USB
Devices Non-
Bootable
Exclude USB in Boot Table.
[Enabled] - This removes all USB Mass Storage devices
as Boot options.
[Disabled] - This allows all USB Mass Storage devices as
Boot options.
Grayed out if the USB Controller is
disabled.
10 sec
20 sec
30 sec
40 sec
USB Mass Storage device Start Unit command timeout.
Setting to a larger value provides more time for a mass
storage device to be ready, if needed.
Grayed out if the USB Controller is
disabled.
One line for each
mass storage
device in system
Auto
Floppy
Forced FDD
Hard Disk
CD-ROM
[Auto] - USB devices less than 530 MB are emulated as
floppies.
[Forced FDD] - HDD formatted drive are emulated as a
FDD (e.g., ZIP drive).
Hidden if no USB Mass storage
devices are installed.
Grayed out if the USB Controller is
disabled.
This setup screen can show a
maximum of eight devices on this
screen. If more than eight devices
displays the
correct count, but only displays the
first eight devices.
Onboard USB ports are enabled to support USB 2.0 mode.
Contact your OS vendor regarding OS support of this
feature.
Grayed out if the USB Controller is
disabled.
5.3.2.2.6 PCI Screen
The PCI Screen allows the user to configure the PCI add-in cards, onboard NIC controllers, and
video options.
To access this screen from the Main screen, select Advanced > PCI.
