Intel

Server Board S5500BC TPS Product Overview

Revision 1.8 Intel order number: E42249-009 13

2.2.3 Intel

Light-Guided Diagnostic LED Locations

Figure 10. Intel

Light-Guided Diagnostic LED Locations

Table 3. Intel

Light-Guided Diagnostic LED reference

Description

Post-Code Diagnostic LEDs

Status LED

System ID LED

HDD LED

System Fan 3 Fault LED

5 VSB LED

DIMM Fault LED

System Fan 2 Fault LED

CPU 1 Fan Fault LED

CPU 2 Fan Fault LED

System Fan 1 Fault LED

DIMM Fault LED
