Intel SC5650BCDP Technical Product Specification

BIOS Setup Utility Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
64
Advanced
Memory Configuration
Total Memory
<Total Physical Memory Installed in System>
Effective Memory
<Total Effective Memory>
Current Configuration
<Independent / Mirror / Sparing>
Current Memory Speed
<Speed that installed memory is running at.>
 Memory RAS and Performance Configuration
DIMM Information
DIMM_A1
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_A2
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_B1
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_B2
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_C1
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_C2
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_D1
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_D2
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_E1
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_E2
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_F1
Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_F2
Installed/Not Installed/Failed/Disabled/Spare Unit
Figure 22. Setup Utility — Memory Configuration Screen Display
Table 19. Setup Utility — Memory Configuration Screen Fields
Setup Item
Options
Help Text
Comments
Total Memory
Information only. The amount of memory
available in the system in the form of
installed DDR-3 DIMMs, in units of MB or
GB.
Effective Memory
Information only. The amount of memory
available to the operating system in MB or
GB.
The Effective Memory is the difference
between Total Physical Memory and the
sum of all memory reserved for internal
usage, RAS redundancy and SMRAM.
This difference includes the sum of all
DDR-3 DIMMs that failed Memory BIST
during POST, or were disabled by the
BIOS during memory discovery phase in
order to optimize memory configuration.

Intel SC5650BCDP Specifications

General

Brand	Intel
Model	SC5650BCDP
Category	Server
Language	English
