Server Board S5500BC TPS Appendix E: Intel® Server System SR1630BC
Revision 1.8 Intel order number: E42249-009 143
Appendix E: Intel
®
Server System SR1630BC
The Intel
®
Server System SR1630BC 1U server system is designed to support the Intel
®
Server
Board S5500BC. The server board and the system have features designed to support the high-
density server market.
For more information, refer to the Intel
®
Server System SR1630BC Technical Product
Specification (TPS).
A
Rack handles (two)
F
CPU Heatsink (two)
B
Processor air duct
G
System blower fans (two)
C
System memory DIMM sockets
H
Hard drives (two)
D
PCI add-in card bracket
I
Control panel
E
Power supply
J
Slimline optical drive
Figure 49. 1U Intel
®
Server System SR1630BC Overview
