Intel SC5650BCDP Technical Product Specification

Intel
®
Server Board S5500BC TPS BIOS Setup Utility
Revision 1.8 Intel order number: E42249-009 83
Table 32. Setup Utility — Delete Boot Option Fields
Setup Item
Options
Help Text
Delete Boot Option
Select one to Delete
Internal EFI Shell
Remove an EFI boot option from the
boot order.
5.3.2.6.3 Hard Disk Order Screen
The Hard Disk Order screen allows the user to control the hard disks.
To access this screen from the Main screen, select Boot Options > Hard Disk Order.

Boot Options

Hard Disk #1
< Available Hard Disks >
Hard Disk #2
< Available Hard Disks >
Figure 36. Setup Utility — Hard Disk Order Screen Display
Table 33. Setup Utility — Hard Disk Order Fields
Setup Item
Options
Help Text
Hard Disk #1
Available
Legacy devices
for this Device
group.
Set system boot order by selecting the boot
option for this position.
Hard Disk #2
Available
Legacy devices
for this Device
group.
Set system boot order by selecting the boot
option for this position.
5.3.2.6.4 CDROM Order Screen
The CDROM Order screen allows the user to control the CDROM devices.
To access this screen from the Main screen, choose Boot Options > CDROM Order.

Boot Options

CDROM #1
<Available CDROM devices>
CDROM #2
<Available CDROM devices>
Figure 37. Setup Utility — CDROM Order Screen Display
