Intel SC5650BCDP Technical Product Specification

Intel
®
Server Board S5500BC TPS Product Overview
Revision 1.8 Intel order number: E42249-009 3
Feature
Description
Add-in PCI, PCI Express*
Cards
 Slot6: PCI Express* Gen2 x8 connector with X8 link width that supports half-length
(6.6 inches) adapter (support Riser card)
 Slot7: PCI Express* Gen2 x8 connector with x8 link width that supports half-length
(6.6 inches) adapter
 Slot5: PCI Express* Gen2 x8 connector with x4 link width that supports half-length
(6.6 inches) adapter
 Slot3: PCI Express* x4 connector with x4 link width that supports half-length (6.6
inches) adapter
 Slot4: 5-V PCI 32 bit / 33 MHz connector that supports half-length (6.6 inches)
adapter
Onboard Video
Onboard ServerEngines* LLC Pilot II BMC controller
 Integrated 2D video controller
 64 MB DDR2 667 MHz memory
Onboard Hard Drive
Controller
Support up to six Serial ATA II hard drives through six onboard SATA II connectors
LAN
 Two 10/100/1000 NICs
 One 82574LGbE PCI Express* Network Controller connects to the Gen2 x1
interface on the Intel® IOH 5500 chipset.
 One 82567 Gigabit Network Connection that connects to the Gigabit LAN Connect
Interface / LAN Connect Interface on the Intel® ICH10R.
 Two 10/100/1000 Base-TX Interfaces through RJ-45 connectors with integrated
magnetics.
 Link and Speed LEDs on the RJ-45 Connector.
Fans
Five 4-pin fan headers supporting two processor fans and three system fans
USB
 Four USB 2.0 Ports connected to the Server Rear Panel
 Four USB 2.0 Ports connected to Headers on the motherboard
 One USB 1.1 Port connected to the Integrated BMC for KB/MS function
 One USB 2.0 Port connected to the Integrated BMC for remote storage function
Power Supply
 One main power connector
 Onboard Power generation
 VRD 11.1 processor Core Voltage
 1.2 V Regulator for Processor VTT
 1.1 V Regulator for IOH Core and I/O
 1.05 V Regulator for Intel
®
ICH10R Core
 1.5 V Regulator for the Intel
®
ICH10R
 1.5 V for DDR3 and 0.75V for DDR3 Termination
 3.3 V SB Voltage regulator
 1.8 V AUX, 1.2V AUX, and 0.9V AUX for the Integrated BMC and the DDR2
memory in it
System Management
 Processor on die temperature monitoring from the PECI interface
 Board temperature measurement
 Fan speed monitoring and control
 Voltage monitoring
 IPMI-based server management
