Interroll MultiControl User Manual

Process data
100 Operating and Programming
Byte
Bit
Category
Description
Type
Comment
6
.0
Control
Outputs
Overwrite
Control
Output 1
BOOL
Meaning depends on the
selected state table (such as
‘stop zone’ for the state table
Zone Control)
6
.1
Control
Outputs
Overwrite
Control
Output 2
BOOL
6
.2
Control
Outputs
Overwrite
Control
Output 3
BOOL
6
.3
Control
Outputs
Overwrite
Control
Output 4
BOOL
6
.4
Control
Outputs
Overwrite
Control
Output 5
BOOL
6
.5
Control
Outputs
Overwrite
Control
Output 6
BOOL
6
.6
Control
Outputs
Overwrite
Control
Output 7
BOOL
6
.7
Control
Outputs
Overwrite
Control
Output 8
BOOL

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
