Interroll MultiControl

Process data
Operating and Programming 107
Byte
Bit
Category
Description
Type
Comment
4
.0
Control Inputs
ControlInput1
BOOL
Meaning depends on the
selected state table (such as
‘stop zone’ for the state table
Zone Control)
4
.1
Control Inputs
ControlInput2
BOOL
4
.2
Control Inputs
ControlInput3
BOOL
4
.3
Control Inputs
ControlInput4
BOOL
4
.4
Control Inputs
ControlInput5
BOOL
4
.5
Control Inputs
ControlInput6
BOOL
4
.6
Control Inputs
ControlInput7
BOOL
4
.7
Control Inputs
ControlInput8
BOOL
5
.0
Control
Outputs
ControlOutput
1
BOOL
5
.1
Control
Outputs
ControlOutput
2
BOOL
5
.2
Control
Outputs
ControlOutput
3
BOOL
5
.3
Control
Outputs
ControlOutput
4
BOOL
5
.4
Control
Outputs
ControlOutput
5
BOOL
5
.5
Control
Outputs
ControlOutput
6
BOOL
5
.6
Control
Outputs
ControlOutput
7
BOOL
5
.7
Control
Outputs
ControlOutput
8
BOOL
