JRC JMA-3910-4 User Manual

3 – 50
3.3
3
3.3.23.11 Displaying ／ Clearing CPA Ring
This function is used to select whether the CPA ring is displayed or not.
The ring is displayed at the default setting.
In the true vector mode, the CPA ring is not displayed even when this function is set at "ON".
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
3
key to open the RADAR #3 menu.
3. Press the
3
key to open the EPA menu.
4. Press the
5
key to select "DISPLAY OF CPA RING".
5. Press the
5
key to select "OFF" or "ON".
6. Press the
ENT
key to confirm the setting.
Exit
7. Press the
SUB
MENU
key.
EPA
EPA
Press an item number key.
0. PREVIOUS MENU
1. VECTOR TIME 0 MIN (0-60 MIN)
2. PLOT NUMBER OFF ON
3. LIMITS CPA 1.0 NM (0.1-9.9 NM)
TCPA 15 MIN (1-99 MIN)
4. AUDIBLE WARNING OFF
ON
5. DISPLAY OF CPA RING OFF
ON
6.
7.
8.
9.
To close this menu, Press (SUB MENU) key.
Attention

JRC JMA-3910-4 Specifications

General

Brand	JRC
Model	JMA-3910-4
Category	Marine Radar
Language	English
