JRC JMA-3910-4 User Manual

1 – 3
Spare parts and attachments
Item Code Qty. Remarks
Spare parts 6ZXRD00193 6 Display unit fuse MF60NR-10A
3 Display unit fuse MF60NR-0.5A
3 Display unit fuse MF61-TS7
12 Display unit NSK circuit fuse MF51NN-0.5A
3 Display unit monitor power supply circuit fuse
TSCUL1.5A
2 Scanner unit NKE-1055 carbon brush S00152-5C-70
2 Scanner unit NKE-1056 carbon brush 54511-03
Light blocking hood NPOL30250B 1
Canvas cover MPXP31358 1
Instruction manual 7ZPRD0518 1
1.3 Composition
Equipment componets
Remarks
Radar type Scanner unit Display unit
JMA-3910-4 10 kW
JMA-3910-6 10 kW
JMA-3925-6 25 kW
JMA-3925-7 25 kW
JMA-3925-9 25 kW
Trans-
mitting
output
Band
Inboard
power
supply
Ship's power supply
(when an optional
rectifier is used)
NKE-1055-4
(4ft slot antenna) × 1
NKE-1055-6
(6ft slot anttenna) × 1
NKE-1056-6
(6ft slot antenna) × 1
NKE-1056-7
(7ft slot antenna) × 1
NKE-1056-9
(9ft slot antenna) × 1
NCD-3780
× 1
NCD-3780
× 1
NCD-3780
× 1
NDC-3780
× 1
NDC-3780
× 1
X DC24V
AC200 ／ 220 ／ 230V,
50 ／ 60Hz, 1φ
AC100 ／ 110V,
50 ／ 60HZ, 1φ
