7 – 48
7.5
7
7.5.6 Maintenance Menu
The maintenance menu is used only by our service personnel during installation. Users are requested not to
change the setting.
Maintenance Menu
MAINTENANCE MENU
Press an item number key.
0. PREVIOUS MENU
1. ANTENNA HEIGHT UP to 5m
5–10m 10–20m MORE 20m
2. SERIAL INPUT DEVICE
2AXIS LOG HDG SENSOR RS232C
3. ANTENNA SWITCH
TRANSFER DISCARD
4. PARTIAL MASTER RESET
5. ALL MASTER RESET
6. INTERNAL SETTING to CARD 2
7. CARD 2 to INTERNAL SETTING
8. MEMOLIZE USER SETTING
9. RESTORE USER SETTING
To close this menu, Press (SUB MENU) key.
7.5.6.1 Serial Input Equipment
Set the serial input equipment.
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
9
key twice to open the INIT SETTING #2 menu.
3. Press the
8
key to open the MAINTENANCE MENU.
4. Press the
2
key to select "SERIAL INPUT DEVICE".
5. Pres2s the
2
key to select "2AXIS LOG", "HDG SENSOR" or
"RS232C".
6. Press the
ENT
key to confirm the setting.
Exit
7. Press the
SUB
MENU
key.
To Next Page
