3 – 11
3.2
3.2.8.1 Background Color
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
1
key to open the RADAR #1 menu.
3. Press the
7
key to open the DISPLAY COLOR menu.
4. Press the
1
key to select the background color inside the bearing
scale. (Radar area)
Two colors, including black, are available.
Press the
1
key to select the color for DAY1 and press the
ENT
key.
Press the
1
key again to select the color for DAY2 and press the
ENT
key.
Select the colors for NIGHT1 and 2 in the same way.
5.
Press the
2
key to select the background color outside the bearing scale.
Two colors, including black, are available.
Press the
2
key to select the color for DAY1 and press the
ENT
key.
Press the
2
key again to select the color for DAY2 and press the
ENT
key.
Select the colors for NIGHT1 and 2 in the same way.
6. Press the
SUB
MENU
key.
Display color
DIAPLAY COLOR
Press an item number key.
1. RADAR AREA DAY1: BLK BLU
DAY2:
BLK BLU
NIGIHT1:
BLK BLU
NIGIHT2:
BLK BLU
2. OUTSIDE OF RADAR AREA DAY1: BLK
SKY
DAY2:
BLK SKY
NIGHT1: BLK
SKY
NIGHT2:
BLK SKY
3. TARGET COLOR DAY1:
YEL GRN ORN COLOR
DAY2:
YEL GRN ORN COLOR
NIGIHT1:
YEL GRN ORN COLOR
NIGIHT2:
YEL GRN ORN COLOR
4. RADAR TRAILS COLOR DAY1:
SKY WHT GRN
DAY2:
SKY WHT GRN
NIGHT1:
SKY WHT GRN
NIGHT2:
SKY WHT GRN
To close this menu, Press (SUB MENU) key.
